Our greatest strength is the ability to understand the customer's requirements; our success is very much attributed to our strong teamwork.
We believe that our success and future prospects are directly related to a combination of strengths, including the following:
Tolerance and Accuracy: Investment Castings Tolerances Reference Standard: VDG P690 & IS: 11166:1993, Class 2
- Best ‘Speed to Market’ in industry.
- Cost efficiency.
- World class technology.
- Product range and expansion lend scalability to operations.
- Comprehensive CAD/CAM Works and product development capability.
- High Quality, motivated Human Resources.
- Castings can be supplied as per EN, DIN, JIS, BS & GOST and any other International material standards specified by customers.
- Carbon steel for general use e.g. WCB, WCC, 10619
- Carbon steel for low temperature use e.g. LCB, LCC
- Austenitic Stainless steel for general use, low temperature e.g. CF8, CF8M, CF8C, CF3, CF3M, 1.4308, 1.4408, 1.4581.
- Super austenitic alloys e.g. CN7M, CK3MCUN, SMO254, SMO654.
- Duplex alloys e.g. A890 Gr. 4A, 5A, 6A, CD4MCuN.
- Nickel base alloys e.g. INCONEL625, INCO ALLOY825, CW-6MC, CW-12MW.
- Martensite and Ferritic Steel e.g. CA15, CA40, CA6NM, 1.4008.
Weight and Size Range
Weight: 10 grams to 75 Kg Single piece casting handling at present.
Size: 450 MM Length X 450 mm Width X 350 MM height linear dimensions.
Tolerance
| Permissible Deviations on Dimensions, as per IS 11166:1993 Class 2 | ||||||||||
| Nominal Dimensions | Overall Dimensions in mm. | Center Distance Tolerance For Holes & Bosses | ||||||||
| of Rough Casting | Up to 6 | Over 6 | Over 10 | Over 18 | Over 30 | Over 80 | Over 180 | Over 300 | ||
| Over | Up to | Up to 10 | Up to 18 | Up to 30 | Up to 80 | Up to 180 | Up to 300 | Up to 500 | ||
| 6 | ± 0.10 | ± 0.12 | ± 0.15 | ± 0.20 | ± 0.25 | ± 0.25 | ± 0.30 | ± 0.35 | ± 0.12 | |
| 6 | 10 | ± 0.12 | ± 0.15 | ± 0.25 | ± 0.25 | ± 0.30 | ± 0.35 | ± 0.45 | ± 0.12 | |
| 10 | 18 | ± 0.20 | ± 0.30 | ± 0.35 | ± 0.35 | ± 0.40 | ± 0.55 | ± 0.15 | ||
| 18 | 30 | ± 0.30 | ± 0.40 | ± 0.45 | ± 0.50 | ± 0.65 | ± 0.25 | |||
| 30 | 80 | ± 0.55 | ± 0.55 | ± 0.60 | ± 0.75 | ± 0.35 | ||||
| 80 | 180 | ± 0.60 | ± 0.70 | ± 0.90 | ± 0.45 | |||||
| 180 | 300 | ± 1.00 | ± 1.15 | ± 0.70 | ||||||
| 300 | 500 | ± 2.00 | ± 0.90 | |||||||
Surface Finish:
Surface roughness of Castings are maintained
3.0 R.M.S to 6.0 R.M.S ( Ra)Value.
ValueAddition
- Completely Machined Components.
- NDT – RT / MP / LP
- Any type of Specific Heat treatment
- Physical tests, other than normal standards.
- Additional Tests – Surface roughness test, Salt spray test, IGC Practice A,B,C, E , G8 test, Impact Test as per requirements.
- Coating – Zinc plating , Pickeling & passivation, Electro Polishing, Zinc and Manganese phosphating as per specific standards.
